PB   PBS   Straight Police Batons

The batons are produced from the same durable material (polypropylene) like the police plastic tonfa batons. Although they are comparatively lightweight, they are highly resistant to fracture. The batons can be supplied either with or without a wrist strap. It is also possible to choose the PBS version with a protective shield, which protects the hand against blows.


PB - 17/43 PB - 25/63
The lengths produced inch/cm:
17/43, 19/48, 21/53, 23/58, 25/63

PB - 17/43Hs PB - 25/63Hs
The lengths produced inch/cm:
17/43, 19/48, 21/53, 23/58, 25/63


PBS - 25/63 PBS - 34/86
The lengths produced inch/cm:
25/63, 27/68, 29/73, 31/78, 34/86

PBS - 25/63Hs PBS - 34/86Hs
The lengths produced inch/cm:
25/63, 27/68, 29/73, 31/78, 34/86



Type Weight [g] Length [inch] Length [cm]
PB-17/43 267 17 43
PB-19/48 302 19 48
PB-21/53 337 21 53
PB-23/58 372 23 58
PB-25/63 407 25 63



Type Weight [g] Length [inch] Length [cm]
PBS-25/63 425 25 63
PBS-27/68 460 27 68
PBS-29/73 495 29 73
PBS-31/78 530 31 78
PBS-34/86 568 34 86



For order over 500 pieces of one type of baton, it is possible to produce these types fo the baton:

Type Weight [g] Length [inch] Length [cm]
PB-27/68 442 27 68
PB-29/73 477 29 73
PB-31/78 512 31 78
PB-34/86 568 34 86



Demonstration of how to protect the hand when the baton Type PBS is used.



Technical specification

Baton diameter at its straight part: 30,5 mm

Handle:

Length - 125 mm
Diameter changes - 26 mm to 32 mm

Shield diameter of the Type PBS:
72 mm

Material:
HIGH RESISTANT POLYPROPYLENE



CHARACTERISTICS TESTING METHOD UNIT VALUE
Flow stress ISO 527 MPa 27
Elongation at fracture ISO 527 % 150
Modulus of elasticity ISO 178 MPa 1300
Izod notch toughness ISO 180
@ +23°C KJ/m2 12,0
@ -20°C KJ/m2 6,8
Charpy impact strength notched ISO 179
@ +23°C   KJ/m2 12,2
@ -20°C   KJ/m2 6,0



Holders for batons

Holder TR-02TR-02Holder TR-04TR-04
